Solar Lighting

Solar Street Lights, Wall Lights & Flood Lights from China — Split Design, 160 lm/W

Looking for split solar street lights for roads, yards and rural projects? EverRay supplies one proven split-design platform that covers all three form factors — solar street lights on poles, solar wall lights on buildings, and solar flood lights for open areas. The principle is the same: the solar panel mounts separately from the lamp head, so the panel sits in full sun while the light sits exactly where you need it. The LED runs at up to 160 lm/W, the patented bat-wing lens throws wide, dark-spot-free coverage along the road, and the built-in motion-sensing mode keeps brightness smart through the night. No wiring, no trenching, no electricity bill — the way outdoor lighting gets done across Africa, Southeast Asia and Latin America.

All units are part of our one-stop PV + storage portfolio, so distributors can consolidate lighting, solar modules, batteries and inverters with a single supplier — one shipment, one contact, one warranty channel.

---

Featured Model: EVR-SL-WALL Split Solar Street / Wall / Flood Light

Key Features

• Split design — panel installed separately from the lamp head; place the panel in full sun and the light exactly where it is needed
• Up to 160 lm/W efficacy — brighter roads with less energy
• Patented bat-wing lens — wider coverage, no dark spots along streets and roads
• IPC 5.0 five-level smart algorithm — automatically balances brightness and runtime through the night
• 6 working modes (DEMO / OFF / L / T / M / U) — including a motion-sensing mode that idles at low brightness and boosts to full output when people or vehicles approach
• Li battery rated for 2,000+ cycles — years of nightly operation, zero electricity cost
• IP65 weatherproof housing — built for permanent outdoor installation in rain, dust and heat

Technical Specifications

Item	Specification
Light source	LED, up to 160 lm/W
Battery / cycle life	Li battery / >2,000 cycles
Smart modes	DEMO / OFF / L / T / M / U (6 modes, incl. motion-sensing)
Optics	Patented bat-wing lens, dark-spot-free road coverage
Ingress protection	IP65 weatherproof housing
Charging	Separate solar panel, split mounting
Applications	Roads and streets, yards, campuses, rural outdoor lighting

---

Typical Applications

• Rural street lighting programs — township roads and village streets where extending the grid costs more than the lights themselves
• Wall and security lighting — courtyards, homes, farms and warehouses; motion-activated brightness deters intruders
• Campus and community lighting — schools, clinics and community grounds
• Government and NGO electrification tenders — volume pricing and documentation for bid packages

---

Why Add Solar Lighting to Your Product Line

• Zero-running-cost selling point — easy to explain, easy to sell to municipalities, farms and rural communities
• No grid required — ideal for off-grid regions across Africa, Southeast Asia and Latin America
• Small, light, high-volume — low logistics cost per unit, fast inventory turnover for distributors
• Bundles naturally — pairs with the solar modules and batteries you already source from EverRay

---

How to Specify a Solar Street Light: Lumens, Pole Height and Spacing

Most solar lighting enquiries fail at specification stage, because a solar street light can mean anything from a 20W garden lamp to a 200W highway fixture. Three numbers decide the product:

Road type	Pole height	Typical output	Spacing
Footpath, garden, compound	3-4m	20-40W	10-15m
Local street, village road	5-6m	40-60W	15-20m
Main street, parking area	7-8m	60-100W	20-25m
Highway, trunk road	9-12m	100W and above	25-35m

Luminous efficacy matters more than raw wattage: at 160 lm/W our split fixtures deliver roughly double the light of an older 70 lm/W lamp at the same rated power, so a 60W model can replace a 120W legacy fixture.

---

Split or All-in-One: Which Solar Street Light Design Wins?

All-in-one units put panel, battery and lamp in one housing, which makes transport and installation simple. Split designs mount panel, battery and lamp separately, which lets you aim the panel at the sun while the lamp points at the road.

Where shading, mounting angle or high ambient temperature is a factor, split wins clearly — and it survives better, because the battery is not sitting directly under the panel in full sun. That is why we supply our street, wall and flood light series as split units with the panel and lamp on separate cables.

---

Solar Lighting for Tenders and Municipal Projects

Tender buyers need documentation before they need product: lumens output measured at a stated point, IP rating, battery cycle life, warranty terms and a bill of materials per pole position. We supply the datasheet, photometric values for the fixture class and a pole-position layout you can attach to the bid.

We also consolidate lighting with modules, inverters and batteries from the same order, so a municipal contract can ship as one container instead of three separate shipments.

Lighting loads efficiently in a mixed container alongside our solar modules and solar pump systems.

---

Frequently Asked Questions

Does it have a motion sensor?

Yes. The M mode operates as a motion-sensing profile: the lamp idles at low brightness and ramps to full output when movement is detected, extending runtime on the same battery. Mode profiles (L = light control, T = time control) are configured per project.

How long does the light run each night?

The IPC 5.0 smart controller offers 6 working modes that balance brightness and runtime. In standard modes the light runs all night with intelligent dimming; we will recommend the right mode profile for your local sunlight conditions.

Can the panel and lamp be mounted apart?

Yes — that is exactly the advantage of the split design. The panel can be placed in full sun while the lamp head is positioned exactly where light is needed, connected by cable. Panels are matched to the same high-efficiency cells used in our solar module series.

What is the battery lifespan?

The lithium battery is rated for more than 2,000 charge/discharge cycles — typically several years of nightly operation before replacement. For larger storage projects we also supply dedicated LiFePO4 battery systems with up to 10-year warranty.

Do you support project tenders and bulk orders?

Yes. We regularly support distributor and tender business with volume pricing, shipping consolidation with other EverRay products, and technical documentation.

---

What is the difference between split and all-in-one solar street lights?

All-in-one designs combine panel, battery and lamp in a single housing for simpler installation. Split designs keep them separate so the panel can face the sun at the ideal angle while the lamp aims at the road, and so the battery avoids direct solar heat. Split models perform better in shaded, hot or irregular mounting conditions.

How do I choose the right wattage for a solar street light?

Start from the road type and pole height: 20-40W for footpaths at 3-4m, 40-60W for village roads at 5-6m, 60-100W for main streets at 7-8m, and 100W and above for highways. Because our fixtures run at 160 lm/W, you can usually specify one class below an equivalent legacy 70 lm/W product.

Do you support municipal tenders and bulk orders?

Yes. We provide datasheets, IP and lumen specifications, warranty terms, pole layout drawings and bills of materials for tender documentation, plus mixed-container consolidation with our other product lines.

Get Your Solar Lighting Quotation in 24 Hours

Tell us your market, expected quantities and lighting scenarios — our team will recommend the right configuration and send a formal quotation within one business day.
