N-Type TOPCon & HJT Dual Glass Solar Modules (440W – 735W)

EverRay Solar supplies N-type dual glass solar modules covering 35W in six half-cell series — five TOPCon series (full black EVR-440MH-108 to EVR-460MH-108, EVR-520MH-120, EVR-570-600MH-144, EVR-610-650MH-132 and EVR-700-730MH-132) plus one bifacial HJT series (EVR-695HJT-132 to EVR-720HJT-132). Every module is built with N-type cells, tempered glass on both sides and an IP68 junction box, and is certified to IEC 61215, IEC 61730, TUV and CE. Dual glass construction removes the backsheet and the frame-induced potential-induced degradation path, which is why our modules carry a 15-year product warranty and a 30-year linear power warranty.

We ship from Hefei, China to distributors, EPC contractors and PV system integrators in more than 185 countries. Whether you are building a utility-scale ground mount, a commercial rooftop array or a residential system, the tables below list the exact electrical data of every model we supply — all figures are taken directly from our official datasheets.

---

Product Range — Six N-Type Series from 35W

Series	Models	Cell Technology	Power Range	Max Module Efficiency
Full Black TOPCon	EVR-440MH-108 – EVR-460MH-108	N-type TOPCon bifacial, full black, dual glass	440W – 460W	23.02%
Compact TOPCon	EVR-520MH-120	N-type TOPCon, dual glass	520W	24.09%
Rooftop TOPCon	EVR-570MH-144 – EVR-600MH-144	N-type TOPCon, dual glass	570W – 600W	23.21%
Commercial TOPCon	EVR-610MH-132 – EVR-650MH-132	N-type TOPCon, dual glass	610W – 650W	24.06%
Large-Format TOPCon	EVR-700MH-132 – EVR-730MH-132	N-type TOPCon, dual glass	700W – 730W	23.50%
Bifacial HJT	EVR-695HJT-132 – EVR-720HJT-132	N-type HJT bifacial, dual glass	695W – 720W	23.18%

All six series are N-type designs on 182mm (M10) wafers in half-cut layouts, with anodized aluminium frames, IP68 junction boxes and MC4 / MC4-EVO2 connectors. System voltage is rated at 1500V DC, with snow load 5400Pa and wind load 2400Pa. All series carry PID resistance for hot and humid climates.

MOQ, Lead Time and Ordering

Item	Minimum Order	Lead Time
Solar modules — all six N-type series	1 pallet	1–2 weeks

One pallet is enough to place a first order — a low-risk way for distributors and installers to test a series before committing to a full container. Lead time is counted from order confirmation for standard models. OEM and private-label packaging are available on request.

Matching Modules with the Rest of Your System

These modules pair with our hybrid inverters, commercial and industrial energy storage systems and home energy storage systems, so you can source the whole bill of materials from one supplier. Request a wholesale quote and we will match module, inverter and battery capacity for your project.

---

EVR-570MH-144 to EVR-600MH-144: 570W – 600W Dual Glass TOPCon Module

144 half-cells (6×12 + 6×12) on a 2279 × 1134 × 30 mm dual glass laminate weighing 32.0 kg — the sweet spot for rooftop arrays where roof load and handling matter as much as wattage.

Model	Pmax (W)	Vmp (V)	Imp (A)	Voc (V)	Isc (A)	Cell efficiency	Module efficiency
EVR-570MH-144	570	42.66	13.37	50.90	14.35	24.22%	22.05%
EVR-580MH-144	580	42.88	13.53	51.25	14.51	24.64%	22.44%
EVR-585MH-144	585	42.98	13.62	51.40	14.58	24.85%	22.63%
EVR-590MH-144	590	43.08	13.70	51.50	14.68	25.00%	22.82%
EVR-600MH-144	600	43.28	13.87	51.70	14.51	25.66%	23.21%

Cells	144 (6×12 + 6×12)
Dimensions	2279 × 1134 × 30 mm
Weight	32.0 kg ±3%
Glass	2 mm + 2 mm tempered glass (dual glass)
Frame	Anodized aluminium alloy (silver)
Junction box	IP68, three diodes
Connector	Plug and socket
Output cables	PV 4.0 mm²
Max. series fuse	25 A
Packing	37 pcs / pallet, 740 pcs / 40’HQ

---

EVR-610MH-132 to EVR-650MH-132: 610W – 650W Dual Glass TOPCon Module

132 half-cells (6×11 + 6×11) on a 2382 × 1134 × 30 mm laminate at 34 kg. This is our volume commercial series — high module efficiency with a compact 1.13 m width that keeps rail and racking cost down.

Model	Pmax (W)	Vmp (V)	Imp (A)	Voc (V)	Isc (A)	Cell efficiency	Module efficiency
EVR-610MH-132	610	40.56	15.04	48.60	15.68	24.42%	22.58%
EVR-620MH-132	620	40.88	15.17	48.92	15.84	24.82%	22.95%
EVR-630MH-132	630	41.20	15.30	49.24	15.99	25.22%	23.32%
EVR-640MH-132	640	41.30	15.50	49.64	16.11	25.62%	23.69%
EVR-650MH-132	650	41.58	15.64	49.92	16.27	25.76%	24.06%

Cells	132 (6×11 + 6×11)
Dimensions	2382 × 1134 × 30 mm
Weight	34 kg ±3%
Glass	2 mm + 2 mm tempered glass (dual glass)
Junction box	IP68, three diodes
Max. series fuse	25 A
Packing	37 pcs / pallet, 740 pcs / 40’HQ

---

EVR-700MH-132 to EVR-730MH-132: 700W – 730W Large-Format Dual Glass TOPCon Module

Our highest-output series: 132 N-type TOPCon half-cells (6×11 + 6×11) on a 2384 × 1303 mm laminate. At up to 730W per module you need fewer modules, fewer clamps and less labour per megawatt — the economics utilities care about.

Model	Pmax (W)	Vmp (V)	Imp (A)	Voc (V)	Isc (A)	Cell efficiency	Module efficiency
EVR-700MH-132	700	41.29	16.96	49.68	17.61	24.29%	22.53%
EVR-710MH-132	710	41.59	17.08	49.84	17.81	24.63%	22.85%
EVR-720MH-132	720	41.89	17.19	50.00	18.00	24.98%	23.17%
EVR-730MH-132	730	42.19	17.31	50.16	18.19	25.33%	23.50%

Cells	132 (6×11 + 6×11)
Dimensions	2384 × 1303 × 30 mm
Weight	38.7 kg ±3%
Front glass	2 mm tempered glass
Back glass	2 mm heat strengthened glass
Junction box	IP68, three diodes
Max. series fuse	30 A
Packing	37 pcs / pallet, 666 pcs / 40’HQ

---

EVR-520MH-120: 520W Compact Dual Glass Module

120 half-cells (6×10 + 6×10) on a 1903 × 1134 mm laminate at only 27.5 kg — designed for residential rooftops and constrained commercial roofs where access and weight limits rule out larger formats.

Model	Pmax (W)	Vmp (V)	Imp (A)	Voc (V)	Isc (A)	Cell efficiency	Module efficiency
EVR-520MH-120	520	36.87	14.11	42.76	15.20	26.68%	24.09%

Cells	120 (6×10 + 6×10)
Dimensions	1903 × 1134 × 30 mm
Weight	27.5 kg ±3%
Glass	2 mm + 2 mm tempered glass (dual glass)
Max. series fuse	25 A
Packing	37 pcs / pallet, 888 pcs / 40’HQ

---

EVR-695HJT-132 to EVR-720HJT-132: 695W – 720W Bifacial HJT Dual Glass Module

Our premium heterojunction (HJT) series: 132 N-type HJT half-cells (6×22) on a 2384 × 1303 × 33 mm dual glass laminate at 37.5 kg. HJT cells pair crystalline silicon with thin-film passivating layers, giving the lowest temperature coefficient in our range (−0.26 %/°C) and a bifaciality factor of 80% ± 5% — on high-albedo surfaces the rear side adds 5-25% more power, lifting a single module up to 869W.

Model	Pmax STC (W)	Pmax NMOT (W)	Vmp (V)	Imp (A)	Voc (V)	Isc (A)	Module efficiency
EVR-695HJT-132	695	530	40.30	17.25	48.00	18.28	22.37%
EVR-700HJT-132	700	534	40.50	17.29	48.20	18.32	22.53%
EVR-705HJT-132	705	538	40.70	17.33	48.40	18.36	22.70%
EVR-710HJT-132	710	542	40.90	17.37	48.60	18.40	22.86%
EVR-715HJT-132	715	546	41.10	17.41	48.80	18.44	23.02%
EVR-720HJT-132	720	550	41.30	17.45	49.00	18.48	23.18%

Electrical output at different rear-side power gains (referenced to the 695W front side):

Rear-side power gain	5%	10%	15%	20%	25%
Total power output (W)	730	765	799	834	869

Cells	132 N-type HJT half-cells (6×22)
Dimensions	2384 × 1303 × 33 mm
Weight	37.5 kg
Front glass	2.0 mm high-transmittance AR semi-tempered glass
Rear glass	2.0 mm semi-tempered glass
Frame	Anodized aluminium alloy
Junction box	IP68, 3 bypass diodes
Connector	MC4 / MC4-EVO2
Cable	TUV 4 mm² / UL 12 AWG; length +400/-200 mm or ±1200 mm (customizable)
Bifaciality factor	80% ± 5%
Max. series fuse	30 A
Static loading	Snow 5400 Pa / wind 2400 Pa
Packing	33 pcs / carton, 594 pcs / 40’HQ

HJT series differences from the TOPCon series: temperature coefficient of Pmax −0.26 %/°C (TOPCon: −0.29), Voc −0.24 %/°C, Isc +0.04 %/°C, NMOT 44 ± 2 °C. All other ratings (DC 1500V, −40 to +85 °C, IP68, snow 5400 Pa / wind 2400 Pa, Safety Class II) match the TOPCon series.

---

EVR-440MH-108 to EVR-460MH-108: 440W – 460W Full Black Dual Glass TOPCon Module

Our full black series for premium residential and commercial roofs: 108 N-type TOPCon half-cells (6×18) in a compact 1762 × 1134 × 30 mm dual glass laminate at only 20.9 kg. Black anodized aluminium frame, black junction box and busbar-free black back give the module a uniform all-black look, while the N-type TOPCon bifacial cell structure keeps a module efficiency of up to 23.02% and a bifaciality factor of 80% ± 10% — on high-albedo roofs the rear side adds 5-25% more power, lifting a single module up to 575W.

Model	Pmax STC (W)	Pmax NMOT (W)	Vmp (V)	Imp (A)	Voc (V)	Isc (A)	Module efficiency
EVR-440MH-108	440	331	29.72	14.81	34.67	15.95	22.02%
EVR-445MH-108	445	335	29.90	14.89	34.85	16.00	22.27%
EVR-450MH-108	450	339	30.08	14.97	35.03	16.05	22.52%
EVR-455MH-108	455	343	30.26	15.05	35.21	16.10	22.77%
EVR-460MH-108	460	347	30.44	15.13	35.39	16.15	23.02%

Electrical output at different rear-side power gains (referenced to the 460W front side):

Rear-side power gain	5%	15%	25%
Total power output (W)	483	529	575
Module efficiency (%)	24.17	26.48	28.78

Cells	108 N-type TOPCon half-cells (6×18)
Dimensions	1762 × 1134 × 30 mm
Weight	20.9 kg
Front glass	1.6 mm high-transmittance AR-coated tempered glass
Rear glass	1.6 mm coated tempered glass
Frame	Anodized aluminium alloy, black
Junction box	IP68, 3 bypass diodes
Connector	MC4 / MC4-EVO2
Cable	TUV 4 mm² / UL 12 AWG; +400/-200 mm or ±1200 mm (customizable)
Bifaciality factor	80% ± 10%
Max. series fuse	30 A
Static loading	Snow 5400 Pa / wind 2400 Pa
Packing	36 pcs / carton, 936 pcs / 40’HQ

Full black series differences from the main TOPCon series: temperature coefficient of Pmax −0.28 %/°C (main TOPCon: −0.29), Voc −0.24 %/°C, Isc +0.046 %/°C, NMOT 45 ± 2 °C, 1.6 mm + 1.6 mm glass and only 20.9 kg module weight. Warranty and all other ratings match the main TOPCon series.

---

Operating Conditions and Temperature Coefficients

• STC: irradiance 1000 W/m², module temperature 25 °C, AM 1.5
• Operating temperature: −40 °C to +85 °C
• Maximum system voltage: DC 1500 V
• Power tolerance: 0 ~ +3%
• NOCT: 45 °C ± 2 °C
• Temperature coefficient of Pmax: −0.29 %/°C
• Temperature coefficient of Voc: −0.25 %/°C
• Temperature coefficient of Isc: +0.045 %/°C
• Certificates: IEC 61215, IEC 61730, CQC, CE, TUV; ISO 9001:2015, ISO 14001:2015, ISO 45001:2018
• Warranty: 15-year product warranty, 30-year power warranty

The figures above apply to the four main TOPCon series (520W–730W). The full black series and the HJT series differ slightly in temperature coefficients, glass thickness and packing — the exact values are listed in their respective sections above.

---

Warranty: 15-Year Product, 30-Year Power

Every EverRay dual glass module is covered by a 15-year product warranty against manufacturing defects and a 30-year linear power warranty. Because N-type TOPCon cells contain no boron-oxygen defects, they suffer no light-induced degradation (LID), which is what makes a 30-year linear guarantee possible — unlike P-type PERC modules, which typically stop at 25 years.

Product warranty	15 years — materials and workmanship
Power warranty	30 years — linear
Degradation in year 1	≤ 1.0%
Annual degradation after year 1	≤ 0.40% per year
Power output at year 30	≥ 87.4% of nameplate

Our bifacial HJT series (EVR-695HJT-132 to EVR-720HJT-132) carries the same 15-year product and 30-year power warranty with even slower degradation: ≤ 0.375% per year and ≥ 88.12% output at year 30.

For projects that require an extended warranty or a performance guarantee tied to a financing package, contact us with your bankability requirements.

---

Why Buy Solar Panels from EverRay

• Multi-plant supply chain — our own engineering and QC across 20+ vetted plants, screened continuously on quality, price and delivery, so lead times flex with your project
• Pre-shipment inspection — EL imaging and power flash test reports checked before every shipment
• Long-term warranties — 15-year product warranty plus 30-year linear power warranty, backed by factory certificates
• Mixed container loading — combine solar panels with inverters, batteries and mounting in one container to cut your freight cost
• Project-matched selection — we recommend the right series for your climate, roof type and budget, not just what is in stock
• Export experience — PV modules delivered to projects in 20+ countries across Europe, Africa, the Middle East, Latin America and Southeast Asia

---

Applications

• Residential rooftop systems, 3kW-10kW (on-grid & hybrid)
• Commercial & industrial rooftops
• Ground-mounted power plants and solar farms
• Off-grid systems with battery storage
• Solar pumping and rural electrification projects

---

Wholesale Solar Panel Buying Guide for Distributors

Buying solar panels in bulk for distribution or for a ground-mounted project is a different exercise from a residential purchase. Four numbers decide your landed cost and your margin:

• Price per watt — always compare at the same efficiency class and the same Incoterm, because an FOB price and a DDP price are not the same offer
• Container loading — the number of modules per 40HQ container is the biggest single lever on freight cost per watt
• Power tolerance and binning — modules should arrive within the tolerance stated on the datasheet, not as mixed bins
• Certification set — IEC 61215 and IEC 61730 test reports, plus the destination market’s own mark where it applies

We supply the full 35W range and quote per watt at your required quantity, with the container loading plan attached so you can calculate landed cost before you commit.

---

How Many Solar Panels Fit in a Container?

Container loading is the fastest route to a lower cost per watt. Our modules ship in standard export pallets and cartons, and the loading plan is calculated per series because frame size, glass thickness and packing method change with wattage.

Series	Wattage	Why it loads well
108-cell full black	440-460W	Most pieces per container, highest watts per cubic metre
120-cell compact	520W	High loading with easier handling on small roofs
132-cell	610-650W	Mainstream balance of power and loading
144-cell	570-600W	Cost-optimised for large ground arrays
132-cell large format	700-730W	Lowest cost per watt, highest watts per container

Ask for the loading plan for the series you are considering and we will send the pallet configuration and container diagram along with the quotation.

---

TOPCon or HJT — Which Module Should You Stock?

Both are N-type technologies with a better temperature coefficient than older P-type panels, but they suit different buyers.

Choose TOPCon when your market is price-sensitive and your customers want a mainstream, well-understood product. TOPCon dual glass spans 35W, comes in full black for residential aesthetics, and is the most competitive option per watt at volume.

Choose HJT when your customers value maximum yield per square metre or a premium technical story. HJT modules run 695-720W with a bifacial structure, so they suit large ground-mounted and utility projects where bifacial gain and temperature performance matter more than the last cent of cost per watt.

Many distributors carry both — TOPCon as the volume line and HJT as the premium line. If you are unsure which fits your market, send us your competitor price points and we will recommend the split.

Pair these modules with our hybrid inverters and LiFePO4 batteries for a matched system, or read our guide on how to choose a solar panel supplier in China.

---

Frequently Asked Questions

What power range do EverRay N-type dual glass modules cover?

We supply six series: five N-type TOPCon series from 35W — the full black EVR-440MH-108 to EVR-460MH-108 (440-460W), EVR-520MH-120 (520W), EVR-570-600MH-144 (570-600W), EVR-610-650MH-132 (610-650W) and EVR-700-730MH-132 (700-730W) — plus a bifacial N-type HJT series from 695W to 720W (EVR-695HJT-132 to EVR-720HJT-132).

What is the difference between the 144-cell and the 132-cell series?

The EVR-570-600MH-144 series uses 144 half-cells (6×12 + 6×12) in a 2279 × 1134 × 30 mm laminate at 32.0 kg. The EVR-610-650MH-132 and EVR-700-730MH-132 series use 132 half-cells (6×11 + 6×11); the 610-650W version measures 2382 × 1134 × 30 mm at 34 kg, and the large-format 700-730W version measures 2384 × 1303 × 30 mm at 38.7 kg.

Are these modules bifacial or dual glass?

They are dual glass modules: the 570-600W and 610-650W series use 2 mm + 2 mm tempered glass, and the 700-730W series uses 2 mm tempered front glass with a 2 mm heat-strengthened back glass. All models use an IP68 junction box with three diodes.

What warranty and certification do you offer?

Every module carries a 15-year product warranty and a 30-year power warranty, and is certified to IEC 61215, IEC 61730, CQC, CE and TUV. Our factories operate under ISO 9001:2015, ISO 14001:2015 and ISO 45001:2018.

How are the modules packed and how many fit in a container?

The TOPCon series ship 37 pcs per pallet. Loading for a 40’HQ container is 740 pcs for the 570-600W and 610-650W series, 666 pcs for the 700-730W series, and 888 pcs for the EVR-520MH-120. The full black 440-460W series ships 36 pcs per carton, 936 pcs per 40’HQ, and the HJT series ships 33 pcs per carton, 594 pcs per 40’HQ.

Can you supply OEM branding and wholesale quantities?

Yes. We supply distributors, EPCs and system integrators worldwide with OEM/ODM branding, and we can quote FOB, CIF or DDP. Send us your target wattage, quantity and destination port and we will reply with a full quotation and datasheet.

What is the difference between your TOPCon and HJT modules?

Both are N-type dual glass modules. The TOPCon series (520-730W) is our volume range with module efficiency up to 23.50% and a 30-year linear warranty at ≤0.40% yearly degradation. The HJT series (695-720W) uses heterojunction cells with a lower temperature coefficient (−0.26 %/°C), 80% ± 5% bifaciality for 5-25% rear-side power gain, and even slower degradation (≤0.375% per year, ≥88.12% output at year 30) — the premium choice for high-irradiance, high-albedo utility-scale sites.

What is the minimum order quantity (MOQ)?

MOQ is flexible depending on the series and destination. Sample orders and LCL shipments are supported for new partners — contact us with your requirement.

Can I mix different products in one container?

Yes. Mixed loading of solar panels, inverters, batteries and mounting structures is one of our core advantages as a one-stop supplier — it maximizes container utilization and reduces your landed cost.

---

How many solar panels fit in a 40ft container?

The figure depends on the series, not only the wattage — a 108-cell 450W module loads far more pieces per container than a 132-cell 730W module. Send us the series you are considering and we will return the exact pallet and container loading plan with the quotation.

Can you quote solar panels per watt at volume?

Yes. Bulk orders are quoted per watt in USD at the Incoterm you request — FOB, CIF or DDP — with the container loading plan and certification set included, so you can calculate landed cost accurately before ordering.

Should I stock TOPCon or HJT modules?

Most distributors stock TOPCon as the volume line because it covers 35W at the most competitive cost per watt, then add HJT as a premium line for large ground projects where bifacial gain matters. Both are N-type dual glass and both load into a mixed container.
