Hybrid Inverters — Single Phase, Split Phase & Three Phase (2kW – 150kW)

EverRay supplies a complete hybrid inverter lineup for every market: a proven 2–12kW global series for 24V and 48V battery systems, a 5kW single phase hybrid inverter for homes, NEMA 4X / IP66 rated North & Latin America models with split phase 120/240V output from 10kW to 16kW, and three phase hybrid inverters from 30kW to 150kW for commercial projects — a 60kW hybrid inverter is our best-selling C&I class. Whether you need an off grid solar inverter for a remote home or a three phase unit for a factory, the platform is the same: pure sine wave output, built-in MPPT solar charging and automatic grid/battery switchover — the heart of every reliable solar + storage system. Project buyers usually land on one of three sizes with their own page: 30kW three-phase hybrid inverter, 50kW three-phase hybrid inverter, and 60kW three-phase hybrid inverter.

Phase and voltage selector: single phase 230V for homes across Africa, the Middle East, Europe and Southeast Asia; split phase 120/240V for North and Latin American homes; three phase 380/400V for factories and mini-grids. Battery systems run at 48V and 51.2V across the range, with 24V (and 12V on the smallest 2–3.6kW models) also supported.

---

Global 2–12kW Series — Single Phase, 24V / 48V Battery Systems

For Africa, the Middle East and Southeast Asia, the 2–12kW series covers 24V and 48V battery systems — the workhorse for off-grid homes, shops and farms. Standard models are 2kW, 3kW, 5kW, 8kW, 10kW and 12kW, all with single phase output and built-in MPPT charging.

Model	Rated Output	Battery	MPPT	Enclosure
EVR-H5K	5kW single phase 230V	24V / 51.2V LiFePO4	2 MPPT, 60–450V, 9kW max PV	IP20, indoor wall mount
EVR-H6.5K	6.5kW single phase	51.2V, 120A charge	2 MPPT, 60–450V	IP20
EVR-H8K	8kW single phase	51.2V, 200A charge	2 MPPT, 120–550V	IP65, parallel up to 8 units
EVR-H10K	10kW single phase	51.2V, 200A charge	2 MPPT, 120–550V	IP65, parallel up to 8 units

Typical pairings: a 2kW or 3kW unit for a small home running lights, fans and a TV; 5kW for a medium home with a fridge and washing machine; 8kW to 12kW for a large home with full backup and air conditioning. All are pure sine wave with LiFePO4 battery communication support, and pair naturally with our solar module range.

Every model in this series runs fully off grid — as a 10kW off grid solar inverter for a farm or lodge with no utility connection, or in hybrid mode selling surplus solar where regulations allow. All models are true 48V hybrid inverters (48V / 51.2V LiFePO4 with BMS communication; the 2–5kW class also supports 12V and 24V banks).

---

MOQ, Lead Time and Ordering

Item	Minimum Order	Lead Time
Hybrid inverters — all power classes	1 unit	1–2 weeks

Single units are accepted, so you can take one inverter as a sample before scaling to a container order. Lead time is 1–2 weeks from order confirmation for standard models. EU and US standard versions are both available, and OEM branding is offered on request.

North & Latin America Standard Models (NEMA 4X) — Split Phase 120/240V

Engineered for the Americas: split phase output, NEMA 4X outdoor-rated enclosure, high PV input and strong battery charging — suitable for whole-home backup and light commercial loads.

Model	Rated Output	Battery	Key Specs	Ingress Rating
EVR-H10K	10kW / 48V	48V lead-acid or LiFePO4	Pure sine wave, parallel-capable, 27 kg	NEMA 4X
EVR-H16K	16kW / 48V	48V lead-acid or LiFePO4	Pure sine wave, high-power single unit	NEMA 4X
EVR-H12K	12kW / 51.2V	51.2V LiFePO4, 250A charge	3 MPPT (150–450V PV), parallel up to 6 units, 45 kg	IP66
EVR-H15K	15kW / 51.2V	51.2V LiFePO4, 275A charge	3 MPPT, parallel up to 6 units, 50 kg	NEMA 4X

Under the skin, the 12kW and 15kW wall-mounted models are our EVR-H split-phase platform: 8kW / 10kW / 12kW / 15kW rated output at 120/240V split phase (208V 2/3-phase selectable), 51.2V lithium or lead-acid battery with up to 275A charge current, 3 MPPT trackers with 120–480V MPPT window (550V max DC) and 26+26A PV input, 200% overload for 10 s, parallel capability, and an IP66 outdoor enclosure certified to UL 1741:2021 and FCC Part 15B. For 110/127V grids across Latin America and the Caribbean, the EVR-H4K / H5K models deliver 4kW or 5kW single phase at 100/110/120/127V with 24V or 48V battery input. Spanish-speaking buyers can review our Spanish-language BESS and hybrid inverter page for Latin America.

---

60kW Hybrid Inverter — Three Phase for C&I Projects

For factories, commercial buildings and mini-grid projects, our 60kW three phase hybrid inverter (EVR-H60K platform, EU and US versions) delivers:

• 60kW rated three phase output (380/400V, 277/480V or 120/208V variants) with up to 98.9% max efficiency
• 4 MPPT trackers with a 150–850V MPPT window and 1000V max PV input — flexible rooftop array design across different roof faces
• Dual battery inputs, 2×100A charge/discharge (200A total) on high-voltage 150–850V LiFePO4 systems
• 100% three-phase unbalanced output; supports diesel generator input and AC coupling to retrofit existing solar
• Parallel up to 8 units — scale to 480kW for larger plants
• IP66 outdoor-rated enclosure, 5-year warranty, certified to IEC 62109-1/-2, EN 50549-1, VDE-AR-N 4105 (EU) / UL 1741 and FCC Part 15B (US version)

For C&I sites that need storage at the same scale, this inverter pairs with our C&I energy storage systems.

---

30kW Hybrid Inverter — Small Commercial Solar + Storage

The 30kW class is the entry point for shops, workshops, cold rooms and small factories. Two platforms are available:

Platform	Models	Rated Output	MPPT	Battery	Enclosure
EVR-H 3-MPPT (EU)	EVR-H20K / H25K / H29.9K / H30K	20–30kW, 3/N/PE 380/400V	3 MPPT, 150–850V, 40–60A per MPPT	150–800V HV LiFePO4, 140A charge	IP66, 480×665×270 mm, 54 kg
Deye SUN-30K-SG02HP3-EU-AM3	SUN-25K / 29.9K / 30K	30kW, 3L+N+PE 220/380V, 230/400V	3 MPPT (2+2+2), 150–850V, max PV 48kW	160–700V HV, 75A, pairs with 204.8V / 314Ah HV racks (64–225 kWh)	IP65, 448×688×270 mm, 46 kg

The Deye-based 30kW + 64kWh package (SUN-30K-SG02HP3-EU-AM3 with 64 kWh 204.8V / 314Ah HV racks) is our standard small-scale C&I storage solution: 98.5% max efficiency, 100% unbalanced output, 10-unit parallel capability, ≥10,000-cycle LFP racks and 6 time periods for battery scheduling. See the full package on our C&I energy storage systems page, or read the 30kW / 64kWh system guide for sizing arithmetic and payback by site type.

---

100kW Hybrid Inverter — Large Commercial & Mini-Grid

For loads above 60kW, two paths are available. A single 100kW three phase hybrid inverter from our EVR-H80K~150K series — 80/100/125/150kW rated output, 10 MPPT trackers, 180–850V MPPT window, 1000V max PV, and dual 200A battery ports (up to 400A total) on 150–600V high-voltage LiFePO4 — all in one 780×710×336 mm IP66 cabinet at 139 kg. Alternatively, parallel two 60kW hybrid inverters for a 120kW bank: the platform supports up to 8 units in parallel, so the same 60kW fleet scales from 60kW to 480kW. Both configurations accept generator input and AC-coupled retrofit arrays; tell us your load profile and we will recommend the cheaper route.

---

Key Features Across the Lineup

• Hybrid flexibility — off-grid, on-grid and hybrid operation with automatic backup switching during outages
• Built-in MPPT charging — up to 10 trackers on the 80–150kW C&I models for maximum solar harvest
• Pure sine wave output — safe for fridges, pumps, air conditioners, computers and medical devices
• Wide battery compatibility — LiFePO4 with communication protocols, plus Gel/AGM with configurable profiles
• Parallel scaling — from 6-unit residential banks to 8-unit 480kW commercial arrays
• Outdoor-ready enclosures — NEMA 4X and IP66 rated models for harsh environments
• Smart monitoring — LCD display plus WiFi/app monitoring for real-time system status
• Full protection suite — overload, short-circuit, over-temperature, anti-islanding and battery protections

---

How to Choose Your Inverter

Your Scenario	Recommended Range	Series
Small home, lights + fans + TV	2kW – 3kW	Global series (12V / 24V)
Medium home with fridge & washing machine	3kW – 5kW	Global series (24V / 48V)
Large home, full backup, air conditioning	5kW – 12kW	Global series 48V or EVR-H12K
North/Latin America home backup (split phase)	10kW – 16kW	EVR-H NEMA 4X series
Shop, office, farm or factory loads	30kW – 150kW	30/60kW three phase, 80–150kW series, parallel to 480kW+

Not sure which model fits your market? Send us your load list and grid standard — we size the inverter, battery and PV array for free.

---

Why Source Inverters from EverRay

• Matched system supply — inverters, batteries, modules and mounting from one supplier, tested to work together
• Audited factory base — sourced from vetted production lines with consistent quality and stable supply
• Pre-shipment testing — every batch function-tested before loading
• Mixed container loading — combine inverters with modules and batteries to save freight
• Field-proven — deployed in off-grid, hybrid and on-grid projects across the Americas, Africa, the Middle East and Southeast Asia

---

Applications

• Whole-home backup power in North and Latin America (split phase 120/240V)
• Off-grid home power systems in remote areas
• Hybrid solar + storage for daily energy-bill reduction
• Backup power for shops, clinics and farms
• Factory rooftop and mini-grid C&I systems with 30–150kW three phase units

---

Hybrid, String or Off-Grid Inverter — Which Does Your Project Need?

The three names describe different jobs, and choosing the wrong one is the most common and most expensive specification mistake.

Type	What it does	Choose it when
String inverter	Converts PV DC to grid AC. No battery, no backup.	Cheapest solar-only grid-tied installation
Hybrid inverter	PV, battery and grid together, with automatic backup and battery management built in.	Storage, backup power or off-grid capability is required
Off-grid inverter	Battery and PV only, with no grid interaction.	Sites with no grid connection at all

Most projects today choose the hybrid route, because a hybrid inverter lets you install solar first and add batteries later without replacing the inverter. For the full technical comparison, including efficiency, cost and retrofit paths, read our guide to hybrid inverter vs string inverter.

---

Sizing the Battery Bank Behind a Hybrid Inverter

The inverter’s battery voltage class decides what storage you can connect, so read the two together:

• 24V / 48V low-voltage systems — the 2-12kW single phase series, paired with LiFePO4 batteries in 12.8V or 51.2V modules, wired in series or parallel
• High-voltage battery systems — the 30-60kW three phase models, using stackable high-voltage packs for larger commercial sites

A practical starting point is 1.5-2kWh of usable battery per kW of inverter for a typical daily-cycle residential system, and more where the site needs overnight or multi-day autonomy. The inverter’s maximum charge and discharge current caps how fast the bank can cycle, so an undersized bank clips the inverter’s potential.

---

What Is a Split Phase Hybrid Inverter?

Split phase means the inverter supplies 120/240V from a single unit — the standard household arrangement in the United States, Canada, Mexico and much of Latin America. A split phase hybrid inverter delivers 240V for heavy loads such as pumps, dryers and air conditioning while still providing 120V for lighting and outlets, and it accepts a 240V generator input for backup.

Our NEMA 4X split phase range is built exactly for those markets, with outdoor-rated enclosures and UL 1741 compliance for grid interconnection. If you distribute in North or Latin America and currently resell European 230V single-phase inverters, this is usually the product your installers actually need.

---

Frequently Asked Questions

Should I choose a single phase or three phase hybrid inverter?

It depends on your grid connection and load size. Single phase 230V covers most homes in Africa, the Middle East, Europe and Southeast Asia, typically from 2kW to 12kW including the popular 5kW class. Three phase 380/400V is required for factories and mini-grids from 30kW to 150kW. North and Latin American homes use split phase 120/240V.

What is the difference between off-grid and hybrid inverters?

An off-grid inverter works without any utility connection. A hybrid inverter adds grid interaction: it can sell excess solar to the grid where regulations allow and switch seamlessly between grid, battery and solar during outages. All EverRay models run in both modes.

Do you have inverters for the North American market?

Yes. The EVR-H10K/H16K and EVR-H12K/H15K split phase models are built for the Americas with NEMA 4X outdoor enclosures and 48V/51.2V batteries, and the three-phase 30-70kW series is certified to UL 1741 for 120/208V and 277/480V grids.

Can I use lithium batteries with these inverters?

Yes. Our inverters support LiFePO4 batteries with communication protocols as well as Gel/AGM with configurable charging profiles, on both 48V and high-voltage 150-850V battery systems. See our LiFePO4 battery range for matching models.

Can multiple inverters work together?

Yes. Residential models support parallel connection of up to 8 units, and the three-phase C&I platform supports up to 8 units in parallel, scaling a 60kW hybrid inverter bank to 480kW.

Is the 60kW hybrid inverter certified for the US market?

Yes. The US-standard series covers 30–70kW at 120/208V and 277/480V, certified to UL 1741 and FCC Part 15B, and supports mixed single- and three-phase loads — so a 60kW hybrid inverter can serve a US commercial site without a separate step-down transformer. The EU series (29.9–60kW, 380/400V) is certified to IEC 62109, EN 50549-1 and VDE-AR-N 4105.

Do you offer a NEMA 4X hybrid inverter for outdoor installation?

Yes. Our North and Latin America models (EVR-H10K/H16K, EVR-H12K/H15K) come in NEMA 4X outdoor-rated enclosures — sealed against rain, dust and corrosive coastal air — and the three-phase C&I series is IP66 rated, which meets the same outdoor-protection intent. Mounting, wiring boxes and surge protection accessories are quoted together so the whole string is weather-ready.

What is the MOQ and lead time?

MOQ is 1 unit for standard models, and sample or trial orders are welcome. Lead time is 1–2 weeks from order confirmation for standard configurations; 2–4 weeks applies only to custom-configured or OEM-labelled orders.

---

What size hybrid inverter do I need for a 10kW solar array?

As a rule the inverter is sized close to the array’s peak output, so a 10kW array normally pairs with an 8-12kW hybrid inverter, subject to the local grid-connection limit and export cap. A DC/AC ratio slightly above 1 is acceptable within the datasheet limit, but an undersized inverter caps your yield permanently.

What is the difference between a hybrid inverter and a string inverter?

A string inverter only converts PV DC to grid AC. A hybrid inverter also manages a battery, provides automatic backup during outages and can run off-grid or export to the grid. Our range covers 2kW to 150kW, including the 60kW three phase model that parallels to 480kW for commercial sites.

Do your inverters support 120/240V split phase output?

Yes. The North and Latin America range is built as split phase 120/240V with NEMA 4X outdoor-rated enclosures and UL 1741 compliance, in 10kW, 12kW, 15kW and 16kW models.

Get Your Inverter Quotation in 24 Hours

Tell us your load list, battery type and target market — our engineers will size the inverter, battery and PV array and send a formal quotation within one business day.
